Replacing the Buckle on a QuickFit 20 Watch Band
Garmin recommends that you take your watch to a jeweler if your buckle hardware needs to be replaced. The buckle of a compatible watch can be replaced with another buckle from a QuickFit® 20 band.
Since we offer so many color combinations, we may not offer a replacement band that offers the same color hardware as your original. Replacing the buckle should only be needed if you have purchased a new QuickFit band, and would like to use the same color of hardware that your old band had.
To replace your watch band buckle you will need the following:
- A clean workspace
- QuickFit 20 band
- Replacement buckle
- Pin removal tool or a precision flathead screwdriver
Replacing the QuickFit 20 Buckle
Select an option below to see steps.
- Use the pin removal tool to push in the buckle pin.
- Remove the buckle.
- Use the pin removal tool to push out the watch pin.
- Remove the tongue piece.
- Push in the buckle pin half way.
- Put the tongue piece in the small gap and push the buckle pin in completely.
- Align the buckle holes with the buckle pin.
- Use the pin removal tool to push in the buckle pin.
- Ensure the buckle pin is secure and the buckle remains in place.
