How to Setup the Quickfit Quarter-turn Bike Mount

The QuickFit® Quarter-turn Bike Mount can be used with select Garmin watches to quickly move the watch from your wrist to your bike. For a list of compatible watches, visit the following page: QuickFit® Quarter-turn Bike Mount.

Installing the Mount

1. Select a secure location to mount the watch where it does not interfere with the safe operation of your bike.
2. Place the rubber base on the back of the bike mount.


   ---

   Example



   ---

3. Place the bike mount on the bike stem.


   ---

   Example



   ---

4. Use the appropriately sized o-rings to secure the bike mount.


   ---

   Example



   ---

5. Compare the numbers printed on the 3 included QuickFit mounts with the number printed on the wristband of the watch to identify the appropriately sized QuickFit Mount.


   ---

   Example



   ---

6. Remove the QuickFit band from the watch.


   ---

   Example



   ---

7. Attach the appropriately sized QuickFit mount to the watch with the release tab at the 6 o'clock position.


   ---

   Example



   ---

8. Once the QuickFit mount has been attached to the watch, place it in the bike mount and rotate it 90 degrees to lock it into place.


   ---

   Example



   ---

9. When you are ready to remove the watch, simply press down on the release tab and lift the watch up from the QuickFit mount.


   ---

   Example



   ---
